Density of Construction Materials

Density of Construction Materials

~ The density of construction materials is the ratio of mass per unit volume.

~ It shows the compactness of construction material.

~ It is also called the unit weight of the substance or material.

~ Its unit is kg/m³ or lb/ft³.

~ It is represented by row (p).

~ Lower dense materials occupy more volume as compared to high dense materials.

~ Mathematically;

           p = m/v

~ Note:

1 kg/m3 = 0.624 lb/ft3

~ The density of construction material determines the sinking property of material which plays a vital role in the design and construction of dams, foundations, etc.

~ The value of density is found for materials, not quantities. So different materials have their own density.

~ The density of  construction materials used in the construction are :





Density of Construction Materials





S.No.

Construction Materials

Density (Kg/m3)

Density (lb/ft3)

1WATER100062.43
Wood (various types)
2Balsa17010.6
3Bamboo300 – 40018.7 – 25
4Pine370 – 53023 – 33
5Cedar38023.7
6Aspen42026.2
7Willow wood42026.2
8African mahogany495 – 85031 – 53
9Honduras mahogany54534
10American red wood45028
11European red wood51031.8
12Spruce (Canadian)45028
13Spruce (Sitka)45028
14Afromosia70544
15apple660 – 83041.2 – 51.8
16Ash (black)54033.7
17Ash (white)67041.8
18Birch67041.8
19Ebony960 – 112059.9 – 69.9
20Elm600 – 81537.4 – 50.8
21Iroko65540.9
22Larch59036.8
23Maple75547.1
24Oak590 – 93036.8 – 58
25Teak630 – 72039.3 – 44.9
26Sycamore59036.8
27Lignam vitae1280 – 137079.9 -85.5
28Sandy soil1800112.3
29Clay soil1900118.6
30Gravel soil2000124.8
31Sandstone2000124.8
32Silt2100131
33Chalk2100131
34Shale2500156
35Sedimentary rocks2600162.3
36Metamorphic rocks2700168.5
37Igneous rocks (felsic)2700168.5
38Igneous rocks (mafic)3000187.2
39Bricks1500-180093.64 -112.3
40Asphalt72145
41Cement144089.8
42Cement mortar2080129.8
43Lime64039.9
44Lime mortar1760109.8
45Concrete (P.C.C)2400149.8
46Concrete (R.C.C)2500156
47Steel7850490
48Stainless steel7480 – 8000466.9 – 499.4
49Aluminum2739170.9
50Magnesium1738108.4
51Cobalt8746545.9
52Nickel8908556.1
53Tin7280454.4
54Lead11340707.9
55Zinc7135445.4
56Cast iron7208449.9
57Copper8940558.1
58Iron7850490
59Glass2580161
